Solid Floor
Underfloor Heating
The 15mm Profix® Panel for 10mm to 12mm diameter pipes enables a high efficiency warm-water underfloor heating system to be installed on a solid floor with the underfloor heating pipework arranged in serpentine configuration.

Suspended Timber Floor
Underfloor Heating
The 15mm Profix® Panel for 10mm to 12mm diameter pipes can be installed on a suspended timber floor to create a high performance warm-water underfloor heating solution.

Acoustic Floor
Underfloor Heating
When combined with a thin compressed rubber acoustic isolation mat, the 15mm Profix® Panel for 10mm to 12mm diameter pipes can be used as an integral part of a warm-water underfloor heating solution, on separating solid floors or separating timber suspended floors, with the added benefit of impact noise reduction.
Highlights

Robust strength protects
pipes from foot traffic during
installation

Panels interlock together
via unique interlocking
features

Multiple fixing points allow
additional mechanical fixings
to be used if required

Self-adhesive backing
reduces need for mechanical
fixings (screws)

Suitable for systems using
a thin flowing screed or
as a dry-fit solution

Pipes held securely by
multiple pipe retention clips
in every panel

Can easily be cut to size
thanks to specially formed
V-shaped grooves

Manufactured in the
UK from 100% recycled
plastic
The Profix® Underfloor Heating Panel is suitable for the following building projects

Underfloor heating for new builds
Warm-water underfloor heating is a cost-effective, energy efficient space heating solution for new build properties.
With their self-adhesive backing and interlocking features, Profix® underfloor heating panels are very quick to installand guarantee the UFH pipework is always positioned at the correct spacing.
Incorporating a Profix® low-temperature warm-water underfloor heating system in a new build property, powered by a heat pump, will provide a ‘future-proofed’ space heating solution complying with the requirements of The Future Homes Standard and The Future Buildings Standard.

With its large surface area, a warm-water underfloor heating system can be an ideal space heating solution for retrofit projects.
At just 15mm in height, and with the added benefit of a self-adhesive backing, Profix® underfloor heating panels offer a very thin, fast-fix solution.
The self-adhesive backing on every 15mm Profix® Panel removes the risk of mechanical fixings compromising any hidden services within the existing sub-floor and, thanks to their very low profile, result in only a minimal increase to the current floor height.
Underfloor heating for renovations
The Profix® Panel and Profix® Panel Plus introduction videos
Profix® Panel
Ultra-Low-Profile
Water Underfloor Heating

Specifications:
Panel size: 600 x 600mm
Pipe diameter: 10mm - 12mm
Total panel height: 15mm
Material: 100% Recycled Plastic
The Profix® Panel is a water pipe retention panel for warm-water underfloor heating and wall heating systems. Designed to incorporate 10mm to 12mm diameter pipes, the panel measures just 15mm, making it the ultimate solution for low-profile underfloor heating.
The Profix® water underfloor heating panel is suitable for both new build and retrofit projects. As with all Profix® products, the panel includes high-quality components that provide reliability and ease of installation. Made from 100% recycled plastic, the panel is self-adhesive backed, providing a fast-fix floor heating solution.
Each Profix® Panel measures 600mm x 600mm x 15mm and features multiple water pipe retention clips in its design to hold the pipe securely in place. In addition, each panel features purpose-made locking features to fasten the panels together.
TECHNICAL INFORMATION SHEETS
View the following technical information for the Profix® Panel
