Solid Floor
Underfloor Heating
The 15mm Profix® Panel for 10mm to 12mm diameter pipes enables a high efficiency warm-water underfloor heating system to be installed on a solid floor with the underfloor heating pipework arranged in serpentine configuration.

Suspended Timber Floor
Underfloor Heating
The 15mm Profix® Panel for 10mm to 12mm diameter pipes can be installed on a suspended timber floor to create a high performance warm-water underfloor heating solution.

Acoustic Floor
Underfloor Heating
When combined with a thin compressed rubber acoustic isolation mat, the 15mm Profix® Panel for 10mm to 12mm diameter pipes can be used as an integral part of a warm-water underfloor heating solution, on separating solid floors or separating timber suspended floors, with the added benefit of impact noise reduction.
Highlights

Robust strength protects
pipes from foot traffic during
installation

Panels interlock together
via unique interlocking
features

Multiple fixing points allow
additional mechanical fixings
to be used if required

Self-adhesive backing
reduces need for mechanical
fixings (screws)

Suitable for systems using
a thin flowing screed or
as a dry-fit solution

Pipes held securely by
multiple pipe retention clips
in every panel

Can easily be cut to size
thanks to specially formed
V-shaped grooves

Manufactured in the
UK from 100% recycled
plastic
The Profix® Underfloor Heating Panel is suitable for the following building projects

Underfloor heating for new builds
Warm-water underfloor heating is a cost-effective, energy efficient space heating solution for new build properties.
With their self-adhesive backing and interlocking features, Profix® underfloor heating panels are very quick to installand guarantee the UFH pipework is always positioned at the correct spacing.
Incorporating a Profix® low-temperature warm-water underfloor heating system in a new build property, powered by a heat pump, will provide a ‘future-proofed’ space heating solution complying with the requirements of The Future Homes Standard and The Future Buildings Standard.

With its large surface area, a warm-water underfloor heating system can be an ideal space heating solution for retrofit projects.
At just 15mm in height, and with the added benefit of a self-adhesive backing, Profix® underfloor heating panels offer a very thin, fast-fix solution.
The self-adhesive backing on every 15mm Profix® Panel removes the risk of mechanical fixings compromising any hidden services within the existing sub-floor and, thanks to their very low profile, result in only a minimal increase to the current floor height.
Underfloor heating for renovations
The Profix® Panel and Profix® Panel Plus introduction videos
The Profix® Highway
manifold packs
strips of retention clips

SPECIFICATION
Panel Dimensions: 210mm x 50mm x 15mm
Material: 100% Recycled Plastic
Pipe Diameter: 10-12mm Pipe
Pipe Runs: 8 runs at 25mm Centres per clip
Perfect for new build and retrofit projects.
The Profix® Highway and manifold packs are strips of retention clips allowing you to run your multiple pipe channels back to the manifold in the most simple and cost effective way.
FEATURES
Future proof low carbon solution, fast heat up, high heat output
BENEFITS
Aligned with UK housing requirements, lower running costs, non invasive and quick to install
ENERGY EFFICIENCY GUIDE
All our systems are energy efficient, but to assist you with your selection we have graded them A to C, where A is the most energy efficient. Note floor coverings can impact heat output.
Energy efficient rating: A
