Efficient. Lightweight. Installation-Ready.
The Progroove® EPS from Epic Insulation is a high-performance underfloor heating board designed for fast, efficient installation and optimal heat distribution. Manufactured from expanded polystyrene (EPS), this panel features precision routed grooves to securely house underfloor heating pipes making it an ideal solution for new build and retrofit projects.
The Progroove® EPS Panel comes in compressive strengths of 100kpa, 200kpa and 400kpa, various thicknesses and is routed to your pipe diameter and spacing requirements. The panels are lightweight, easy to handle and can easily be cut on site reducing labour time and simplifying the installation process.
The Progroove® EPS Panel Is compatible with the Epic Insulation Proplate which enhances heat spread and response times as well as the Epic Insulation low profile overlay board, HiDECK.
(1) Other thickness’ manufactured to order, subject to minimum quantity. (2) Other patterns manufactured to order, subject to minimum quantity. (3) 150 & 400kPa manufactured to order, subject to quantity.
Technical specifications
Thickness’ available
20, 25 ,30mm
Board sizes
600 x 1200mm & 1200 x 1200mm
Channel size (to suit UFH pipe diameter)
10, 12, 14, 15, 16mm
Pipe centre options
150, 200, 300mm
Route patterns
Radius, Bulb, Highway
Strength at 10% compression (EN 826)
100kPa
Thermal conductivity (EN 13163)
0.036 W/mK
Associated aluminium heat diffuser
EPIC Proplate - Single
Order quantity
Boards per pack
N/A
Min order qty
1 board
